Rotary Dryer Manufacturer in India, Rotary Dryer Supplier in India

Rotary Dryer Manufacturers in India

We Shree Sai Equipments are Rotary Dryer Manufacturers in India. We provide a wide range of Rotary Dryer in India. We are well known as Rotary Dryer Manufacturers in India. As per industry norms and standards, we offer premium quality Rotary Dryer Manufacturers in India at the international standards level. We are manufacturers and suppliers of various kinds of Rotary Dryer as per customer requirements.

Shree Sai Equipment is one of the Rotary dryer Manufacturers in India. Shree Sai Equipments has hands-on experience in Rotary Dryer Manufacturers in India and overseas for a wide range of applications.

The Rotary Dryer Manufacturers in India is a type of industrial dryer that is used by bringing it into direct contact with a heated gas to reduce or minimize the liquid moisture content of the material it handles. A long, rotating cylindrical tube, typically supported by concrete columns or steel beams, makes up the dryer.

We are the leading Rotary Dryer Manufacturers in India. The Royal Engineering makes use of raw material of superior quality and the new technical machinery that offers the best Rotary Dryer Manufacturers in India. The entire manufacturing process is carried out by professional guidance and the goods are delivered to the consumer after many quality tests.

In order to convey the material through the dryer under gravity, the dryer slopes slightly so that the discharge end is lower than the material feed end. Stuff to be dried reaches the dryer, and the material is raised by a set of internal fins lining the inner wall of the dryer as the dryer rotates.

It falls back down to the bottom of the dryer as the material gets high enough to roll back off the fins, going through the hot gas stream as it falls. This gas stream may either pass from the feed end toward the discharge end (known as co-current flow) or from the discharge end toward the feed end (known as counter-current flow).

A mixture of air and combustion gases from a burner, in which case the dryer is called a direct heated dryer, may make up the gas stream. Rotary dryers may be categorized as co-current, counter-current, direct-fired, and indirect fired, depending on the design.

Unique Features - Rotary Dryer Manufacturers in India

  • Effective drying of products with high levels of moisture.
  • Handles a broad variety of materials with extended residence times for a large scale.
  • The architecture permits the highest drying temperatures possible.
  • Drying, refrigeration, or calcination.
  • Elevated thermal efficiency.

Application - Rotary Dryer Manufacturers in India

  • Cakes by Suifilter
  • Minerals, fertilizers,
  • Pulp of beets
  • Concentrates of floatation
  • Coal/Cocktail
  • Phosphates, Clays
  • Food for animals
  • Germ, Stillage Sillage
  • Yeah. Sludges.

Rotary Dryer Manufacturers in India travel through a rotating cylinder along with a stream of hot gas through the feed materials. Internal lifts or flights raise the feed and lower it along the length of the dryer in a curtain from top to bottom, cascading. Flights need to be planned carefully to stop certain asymmetry. Double and triple pass units are some rotary dryers where each drum is nestled within the previous drum.

The feed materials are supported and transferred over a series of louvers mounted on an external rotating drum by Rotary louver dryers. Below the feed ring, the hot gas is inserted into a tapered bustle. Prior to being exhausted from the dryer, the air passes through the louvers and then the product.

One of the most common types of Rotary Dryer Manufacturers in India used for large amounts of material with particles 10 mm or larger in size is rotary dryers.

The typical rotary dryer consists of a cylindrical shell made of steel plates slightly inclined (1O to 5O) to horizontal to help the wet material fed for processing is transported, the shell is usually 0.3-5 m in diameter, 5-90 m in length, and 1-5 m rotating.

The Rotary Dryer Manufacturers in India shell tube serves as the body to move the wet feedstock and the number of steam-heated tubes is symmetrically arranged and rotated around the perimeter. Wet material is fed into the dryer's upper end and the material is chosen as the lower end by virtue of rotation and slope of the shell and dried product.

The feed rate, shell rotation speed, the amount of heated air or gases, and their temperature are controlled so that it is correctly dried by the time the material reaches the discharge point of the rotary dryer.

We have more than four decades of experience in the manufacture of various rotary dryers and are continuously in touch with their latest innovations on a global level.

We use revolutionary technologies so that you can stay ahead of your rivals for miles.

As per customer requirement, we are specialized in producing Rotary dryer for drying different products. As per international standards, our rotary dryer is the best rotary dryer with the best technology in the world.

Available in fully automated and semi-automatic versions. The rotary dryer model is available at a very low price. The world's highest-performing rotary dryer.

For drying wet powders or wet cakes that take a long time to dry, rotary dryers are used. The Rotary dryer consists of a hollow drum fitted internally with staggered louvers.

As this drum rotates, the louvers help to lift the product from the top and shower it. At one end of the spinning tank, the wet product is fed.
